Products

Aluminum housing electric motors for hydraulic vane pump

Aluminum housing electric motors for hydraulic vane pump Aluminum housing electric motors for hydraulic vane pump

Product name:Aluminum housing electric motors for hydraulic vane pump

Item:

Details:

Aluminum housing electric motors for hydraulic vane pump

Quick Details

Type:

MVPD hydraulic power unit

ModelNumber:

3 Phase 2HP-4P-20L

Placeof Origin:

China(Mainland)

Frequency:

50/60Hz

Frame:

aluminiumHousing

Motortype:

combination

displacement:

16 cm3/rev

shaftdiameter:

12 mm

flangesize::

50.77mm

Material:

aluminiumhousing

rotation speed:

1500/ 1800 r/min

weight:

16 kg













Supply Ability

SupplyAbility:

10000Piece/Pieces per Month

Packaging & Delivery

PackagingDetails

plasticbag pack pumps,then put into thick carton, then heap up these cartons on theplastic pallet.

Port

SHENZHEN

Characteristic: low noise , small volume, high efficiency, long working life.



1,this vane pump have special inner structure ,can operate with high efficiencyin low pressure. the pressure balance can get best effect through externaldrain oil, further to decrease the temperature, promote the efficiency.



2,pump don’t connect with motor directly ,with indirect coupling ,decrease therequirement of concentricity for pump connect with motor, so that decrease thenoise from shock of shaft and deviated concentricity ,and the hydraulic oil ofconnecting part can lubricate the bearing at the same time, prolong the workinglife.

3, circuit boards and pressure gauge can mount on the pump directly,decrease the cost of pipe ,delivery port setted as both teeth port and flangeconnecting ways.
















Our Services

Warrantyperiod:  ONE YEAR



1,Withinone week after receipt of the goods, if customer use the products in correctmethod,and find any problem of performance or  construction with obviousevidence,we will be responsible for replacement or other discussing solutionbetween us.

2,Butif customer using method are not correct, or customer disassemble our productsprivately,we will not  responsible  for any problem or defectivepoints of products.

3,If you meet any questions of installation or debugging, please inquiry usanytime, our Engineer will provide technical support in time, or we will helpyou to resolve the technical failure through online video.

4,Any damage from transportion, we will slove the problem according to theresponsibility standard of INCOTERMS.
