Maximum service pressure: 250bar(3500psi)

The performance of HYDROMAX new gear pump is as follows:

1. High efficiency: the series of gear pumps have high volumetric rate and high mechanical efficiency through accurate and detailed structural design.

2. Long service life: high anti-wear bearing with excellent performance will not burn up when running at high pressure and high speed.

3. Light weight and compact structure.

4. The body is made of aluminum alloy with high precision and low noise.

5. It is applicable to a wide range of devices, such as civil construction machinery, industrial vehicles, transport machinery, agricultural, forestry and fishery machinery.

This series gear pump other models: gear pump HGP-1A-F0.5R, gear pump HGP-1A-F0.8R, gear pump HGP-1A-F1R, gear pump HGP-1A-F2R, gear pump HGP-1A-F3R, gear pump HGP-1A-F4R, gear pump HGP-1A-F5R, gear pump HGP-1A-F6R, gear pump HGP-1A-F8R

Taiwan Hydromax gear pump HGP1AF2RX2B12, Taiwan Hydromax gear pump HGP-1A-F2R-X-2B-12
Taiwan Hydromax gear pump HGP1AF1RX2B12, Taiwan Hydromax gear pump HGP-1A-F1R-X-2B-12
Taiwan Hydromax gear pump HGP1AF3RX2B12, Taiwan Hydromax gear pump HGP-1A-F3R-X-2B-12
Taiwan Hydromax gear pump HGP1AF4RX2B12, Taiwan Hydromax gear pump HGP-1A-F4R-X-2B-12
Taiwan Hydromax gear pump HGP1AF5RX2B12, Taiwan Hydromax gear pump HGP-1A-F5R-X-2B-12
Taiwan Hydromax gear pump HGP1AF6RX2B12, Taiwan Hydromax gear pump HGP-1A-F6R-X-2B-12
